RC2006SP
|
Models
|
RC2006SP
|
|---|---|
|
Compatibility
|
26 - 50 HP
|
|
Tractor PTO Min
|
20 hp (14.90 kW)
|
|
Tractor PTO Max
|
50 hp (37.30 kW)
|
|
Hitch
|
Category 1
|
|
Cutting Width
|
75 in (1,905 mm)
|
|
Cutting Height Min
|
1.50 in (38.10 mm)
|
|
Cutting Height Max
|
9 in (228.60 mm)
|
|
Cutting Capacity
|
1 in (25.40 mm)
|
|
Gearbox Power
|
45 hp (33.56 kW)
|
|
Blade Tip Velocity
|
14,974 f/s (4,564.10 m/s)
|
|
Weight
|
623 lb (464.60 kg)
|
|
Blade Width
|
3 in (76.20 mm)
|
|
Blade Thickness
|
0.50 in (12.70 mm)
|
|
Tail Wheel
|
15" Laminated Tire
|
|
Frame Construction
|
12-Guage Steel
|
|
Tractor PTO Speed
|
540 rpm
|
|
Transport Width
|
79 in (2,006.60 mm)
|
|
Length
|
109 in (2,768.60 mm)
|
|
Deck Length
|
84.60 in (2,148.84 mm)
|
|
Gearbox Output Shaft Diameter
|
1.57 in (39.88 mm)
|
|
Side Skirt Thickness
|
9 Gauge
|
|
Side Skirt Depth
|
10.50 in (266.70 mm)
|
|
Blade Carrier
|
Oval Stump Jumper
|
|
Blade Mount System
|
—
|
|
Blade Pin Diameter
|
1.50 in (38.10 mm)
|
|
Safety Shielded Driveline
|
Category 3
|
|
Driveline Protection
|
Slip-Clutch
|
|
Quick Hitch Compatible
|
Yes
|
|
Side Skirt Skid Shoes
|
Bolt-on, Replaceable
|
|
Cutting Area Shielding
|
Chain Shielding
|
