For properties up to 5 acres, the KIOTI CS Series sub-compact tractors are the perfect workhorses for your acreage.
Starting At
$17,277.00
/
MSRP does not include: Loader, Accessories, Factory Freight And PDI
  • Available To Order
  • Available To Order

This site is protected by hCaptcha and the hCaptcha Privacy Policy and Terms of Service apply.

KIOTI CS Series Sub-Compact Tractors

For properties up to 5 acres, the KIOTI CS Series sub-compact tractors are the perfect workhorses for your acreage.

Everything you want. Without all the things you don't.

20 Series models offer additional comfort and convenience features: tilt steering wheel, loader joystick on the fender, cruise control, metal floorboard with rubber mat, and phone charger.


Power and Performance
Fuel-efficient KIOTI 3-cylinder diesel engine with smooth-shifting hydrostatic transmission for optimal control. Standard differential lock ensures traction, while rear and mid PTOs and a category I 3-point hitch lets you attach a variety of implements with ease.

Hydrostatic Transmission
Infinite 2-range hydrostatic transmission for effortless control, twin pedals for intuitive forward and reverse movements, seamlessly adjusting speed without ever touching a clutch.

Streamlined Hood Design
Single-lever engaged 4WD is standard on the CS2220 tractor.

Ergonomic Operator Station
The ergonomically designed workstation places operator controls within easy reach for maximum comfort.

Foldable ROPS
The standard fold-down roll bar allows you to move into low clearance areas quickly and easily.

Headlights
55W lamps are the brightest in this tractor's class.

Control Levers
The HST with HI-LO range lever allows the tractor to overcome a wide range of load tasks. The rear PTO and mid PTO can be controlled separately or together with a simple in-line shifting lever. The height adjustment lever allows the operator to easily control the mid-mount mower grass cutting height.

Four Wheel Drive
Single-lever engaged 4WD is standard on the CS2210 tractor.

Twin HST Pedals
Twin HST pedals offer easy forward and reverse movement with smooth engagement, acceleration and deceleration. Pedal pressure is minimized which reduces operator fatigue during long hours of use.

Mid PTO
The standard mid PTO (2,200 rpm) allows you to use implements such as a mid-mount mower.

Illuminated Dashboard
The dashboard illuminates when the engine is started. The digital gauge package includes tachometer, fuel and temperature gauges along with a low fuel warning lamp.
Model 3C100LWH-U3
Engine Manufacturer KIOTI
Power 21 hp (15.60 kW)
Displacement 61.50 cu. in. (1,007 cc)
RPM
Fuel Type Diesel
Aspiration Natural
Fuel Capacity 6.70 gal (25.50 L)



Transmission Hydrostatic
Shuttle Hydrostatic
Main Gear Hydrostatic
Travel Speeds Forward 9
Travel Speeds Reverse 6
Travel Speeds Minimum Speed 0 mph (0 km/h)
Travel Speeds Maximum Speed 9.57 mph (15.40 km/h)
Travel Speeds Min Reverse Speed 0 mph (0 km/h)
Travel Speeds Max Reverse Speed 6.60 mph (10.60 km/h)
PTO Type Independent
PTO Power 16.30 hp (12.20 kW)
Rear Speed 540 rpm
Mid Speed 2,200 rpm
Brakes Wet Multi Disc
Clutch Foot Pedal
Steering Mechanical
Pump Gear
Pump Capacity 7 gpm (26.40 lpm)
Lift Capacity 700 lb (318 kg)
Type Three Point
Category Category 1
Control Type Position
Lift Capacity 1,500 lb (680 kg)
Length with Hitch 99.30 in (2,523 mm)
Height 88 in (2,226 mm)
Width 45.90 in (1,168 mm)
Ground Clearance 6.40 in (162.60 mm)
Front Tread 44.60 in (1,133 mm)
Rear Tread 46 in (1,168 mm)
Turning Radius 8.20 ft (2.54 m)
Weight 1,554 lb (705 kg)
Wheelbase 55.10 in (1,400 mm)





These tires were made for working. And that’s just what they’ll do.

Agricultural

Front: 18-850-10
Rear: 26-12-12

Industrial

Front: 18-850-10
Rear: 26-12-12

R14

Front: 18-850-10
Rear: 26-12-12

Turf

Front: 18-850-10
Rear: 26-12-12

Attachments & Implements

Everything you need to get anything done.

KIOTI

Backhoes

KIOTI backhoes deliver trenching up to 94” deep with a bucket dig force of up to 3,748 pounds. The backhoes feature sub-frame mounting, self-contained hydraulics, two-lever hydraulic controls, hydraulic stabilizers, transport lock and a variety of buckets. Now go dig.
Learn More
KIOTI

Front End Loaders

Built with better lift capacity and a greater lift height.

Dirt, gravel, manure, logs, bags of fertilizer, a giant stump, chicken feed, a pile of fence posts... it it's on your land and it needs to be scooped, lifted, pushed around or carried somewhere, a KIOTI front end loader will get it done.
Learn More

Implements

Example collection
Example collection
Example collection
Example collection
