Ideal for homeowners, and hobby farmers who demand greater lift capacity and ground clearance, these versatile, powerful, and rugged tractors exceed the limitations of entry level tractors.PriceTransmission
Starting At
$19,260.00
/
MSRP does not include: Loader, Accessories, Factory Freight And PDI
  • Available To Order
  • Available To Order

This site is protected by hCaptcha and the hCaptcha Privacy Policy and Terms of Service apply.

CX Series Sub-Compact Tractors

For homeowners, and hobby farmers who demand greater lift capacity and ground clearance. These compact tractors surpass the limitations of entry-level tractors, while maintaining their compact maneuverability.

Everything you want. Without all the things you don't.

For homeowners, and hobby farmers who demand greater lift capacity and ground clearance. These 25 hp compact tractors surpass the limitations of entry level tractors, while maintaining their compact maneuverability.

Manual or Hydrostatic Transmission
Infinite 2-range hydrostatic (HST) transmission for effortless control, twin pedals for intuitive forward and reverse movements, seamlessly adjusting speed without ever touching a clutch.

Convenient Features
Features a comfortable suspension seat, single lever joystick, tilt wheel with power steering, rear PTO, adjustable 3-point hitch, illuminated dashboard, USB and power socket.

Open Station Platform
Every control, every button, every lever falls effortlessly within reach, like an extension of your own will. This intuitive layout isn't just about luxury, it's about efficiency.

Single Lever Joystick
The single lever joystick redefines front-loader operation. With a flick of your wrist, you command every movement, from raising the boom to lowering the bucket. A float position allows the bucket free flotation over the ground surface.
Model 3A165LWH-U2
Engine Manufacturer KIOTI
Power 24.50 hp (18.30 kW)
Displacement 87 cu. in. (1,647 cc)
RPM 2,600 rpm
Fuel Type Diesel
Fuel Capacity 6.60 gal (25 L)



Transmission Manual
Shuttle Manual
Main Gear Manual
Travel Speeds Forward 10
Travel Speeds Reverse 4
Travel Speeds Minimum Speed 0.75 mph (1.22 km/h)
Travel Speeds Maximum Speed 10.80 mph (19.07 km/h)
Travel Speeds Min Reverse Speed 0.92 mph (1.51 km/h)
Travel Speeds Max Reverse Speed 4.20 mph (7.40 km/h)
PTO Type Transmission
PTO Power 19.30 hp (14.40 kW)
Rear Speed 540 rpm
Mid Speed 2,000 rpm
Brakes Wet Multi Disc
Clutch Dry Single Stage
Steering Hydraulic Power Steering
Pump Gear
Pump Capacity 11.30 gpm (42.90 lpm)
Lift Capacity 1,203 lb (546 kg)
Type Three Point
Category Category 1
Control Type Position
Lift Capacity 1,203 lb (546 kg)
Length with Hitch 109.08 in (2,790 mm)
Height 82.80 in (2,103 mm)
Width 49.40 in (1,256 mm)
Ground Clearance 13.40 in (340 mm)
Front Tread 38.10 in (968 mm)
Rear Tread 37.40 in (951 mm)
Turning Radius 9 ft (2.75 m)
Weight 2,308 lb (1,047 kg)
Wheelbase 59.80 in (1,520 mm)





These tires were made for working. And that’s just what they’ll do.

Agricultural

Front: 7.0-12
Rear: 11.2-16

Industrial

Front: 23-8.5-12
Rear: 12-16.5

R14

Front: 23-8.5-12
Rear: 12-16.5

Turf

Front: 23-8.5-12
Rear: 33-12.5-16.5

Attachments & Implements

Everything you need to get anything done.

KIOTI

Backhoes

KIOTI backhoes deliver trenching up to 94” deep with a bucket dig force of up to 3,748 pounds. The backhoes feature sub-frame mounting, self-contained hydraulics, two-lever hydraulic controls, hydraulic stabilizers, transport lock and a variety of buckets. Now go dig.
Learn More
KIOTI

Front End Loaders

Built with better lift capacity and a greater lift height.

Dirt, gravel, manure, logs, bags of fertilizer, a giant stump, chicken feed, a pile of fence posts... it it's on your land and it needs to be scooped, lifted, pushed around or carried somewhere, a KIOTI front end loader will get it done.
